• Rear wheel drive
• 58 amp-hour (540 CCA) maintenance-free battery w/battery-saver feature
• 130 amp alternator
• Trailer tow wiring
• Fail-safe cooling feature
• 6-1/2' pickup box w/(4) tie-down hooks
• 6050# GVWR/2000# maximum payload
• 3450# capacity twin forged SLA front axle
• 3800# capacity rear axle
• Front coil/rear leaf spring suspension
• Gas-pressurized shock absorbers
• P235/70R16SL all-season BSW tires
• Full-size spare tire w/steel wheel
• Underframe crank-type spare tire carrier-inc: spare tire lock
• 16" x 7.0" 5-stud styled steel wheels w/chrome hubs
• Pwr steering
• Pwr front/rear anti-lock disc brakes (ABS)
• 25.0 gallon fuel tank

• Chrome front/rear step bumper
• Chrome grille surround w/grey "egg crate" insert
• Boxrail & tailgate moldings
• Cargo box light
• Dual black manual mirrors
• Solar tint rear window
• Interval wipers
• Black door handles
• Removable tailgate

• Cloth front full bench seat
• Black vinyl floor covering
• Black polyurethane steering wheel
• Securilock anti-theft ignition
• Manual air conditioning
• Electronic AM/FM stereo radio w/cassette-inc: digital clock, (4) speakers
• Dual instrument panel cup holders
• Glove box
• Auxiliary pwr point in instrument panel
• Door trim w/armrest, door pull handle & map pockets
• Dual A-pillar grab handles
• Cloth sunvisors w/LH strap, RH mirror
• Lights-inc: dome light w/dual map lights, underhood light

• Driver & front passenger airbags w/passenger-side deactivation switch
• Pwr front/rear anti-lock disc brakes (ABS)
• Outboard height-adjustable shoulder belts
• Lower Anchors and Tethers for CHildren (LATCH)

4.2L (256) SEFI V6 ENGINE

• (STD)

• 3.08 Axle Ratio
• GVWR: 6,050 lbs Payload Package
• AM/FM Stereo/Clock/Cassette
• 4 Speakers
• Front beverage holders
• Variably intermittent wipers
• Rear step bumper
• Power steering
• Passenger vanity mirror
• Passenger door bin
• Passenger cancellable airbag
• Front wheel independent suspension
• Front reading lights
• Front anti-roll bar
• Dual front impact airbags
• Driver door bin
• Bumpers: chrome
• AM/FM radio
• ABS brakes
• Voltmeter
• Cassette
• 4-Wheel Disc Brakes

• Mileage
• EPA Fuel Economy Est - City (MPG): 17
• EPA Fuel Economy Est - Hwy (MPG): 20
• Electrical
• Cold Cranking Amps @ 0° F (Primary): 540
• Maximum Alternator Capacity (amps): 130
• Maximum Alternator Watts: - TBD -
• Cooling System
• Total Cooling System Capacity (qts): 20.1
• Weight Information
• Gross Axle Wt Rating - Front (lbs): 2500
• Gross Axle Wt Rating - Rear (lbs): 3500
• Curb Weight - Front (lbs): 2281
• Curb Weight - Rear (lbs): 1751
• Gross Vehicle Weight Rating Cap (lbs): 6050
• Gross Combined Wt Rating (lbs): 6,500
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 4,000
• Dead Weight Hitch - Max Tongue Wt. (lbs): 400
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 4,000
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 600
• Fifth Wheel Hitch - Max Trailer Wt. (lbs): 4,000
• Fifth Wheel Hitch - Max Tongue Wt. (lbs): 1,000
• Suspension
• Suspension Type - Front: Coil Spring
• Suspension Type - Rear: 2-Stage Multi-Leaf
• Spring Capacity - Front (lbs): 2500
• Spring Capacity - Rear (lbs): 3500
• Axle Type - Front: Twin Forged SLA
• Axle Type - Rear: Semi-Floating
• Axle Capacity - Front (lbs): 3450
• Axle Capacity - Rear (lbs): 3800
• Axle Ratio (:1) - Rear: 3.08
• Shock Absorber Diameter - Front (mm): 35
• Shock Absorber Diameter - Rear (mm): 35
• Stabilizer Bar Diameter - Front (in): - TBD -
• Brakes
• Brake Type: Power
• Brake ABS System: 4-wheel
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 12.1 x 0.39
• Rear Brake Rotor Diam x Thickness (in): 13.2 x 0.43
• Tires
• Front Tire Order Code: T52
• Rear Tire Order Code: T52
• Spare Tire Order Code: T52
• Front Tire Size: P235/70R16SL
• Rear Tire Size: P235/70R16SL
• Spare Tire Size: P235/70R16SL
• Front Tire Capacity (lbs): 1804
• Rear Tire Capacity (lbs): 1804
• Spare Tire Capacity (lbs): 1804
• Revolutions/Mile @ 45 mph - Front: 719
• Revolutions/Mile @ 45 mph - Rear: 719
• Revolutions/Mile @ 45 mph - Spare: 719
• Wheels
• Front Wheel Size (in): 16.0 x 7.0
• Rear Wheel Size (in): 16.0 x 7.0
• Spare Wheel Size (in): 16.0 x 7.0
• Front Wheel Material: Steel
• Rear Wheel Material: Steel
• Spare Wheel Material: Steel
• Steering
• Steering Type: Power
• Steering Ratio (:1), On Center: 14.0
• Turning Diameter - Curb to Curb (ft): 40.5
• Turning Diameter - Wall to Wall (ft): 42.2
• Frame
• Frame Type: Ladder
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 25.0
• Fuel Tank Location: Midship
• Exterior Dimensions
• Wheelbase (in): 119.9
• Length, Overall w/o rear bumper (in): 206.9
• Width, Max w/o mirrors (in): 79.3
• Height, Overall (in): 73.4
• Overhang, Front (in): 38.7
• Overhang, Rear w/o bumper (in): 48.3
• Front Bumper to Back of Cab (in): - TBD -
• Cab to Axle (in): - TBD -
• Cab to End of Frame (in): - TBD -
• Ground to Top of Load Floor (in): 33.2
• Ground to Top of Frame (in): - TBD -
• Frame Width, Rear (in): - TBD -
• Ground Clearance, Front (in): - TBD -
• Ground Clearance, Rear (in): - TBD -
• Cargo Area Dimensions
• Cargo Box Length @ Floor (in): 78.8
• Cargo Box Width @ Top, Rear (in): 62.1 @ Belt
• Cargo Box Width @ Floor (in): 60.3
• Cargo Box Width @ Wheelhousings (in): 50.0
• Cargo Box (Area) Height (in): 20.0
• Tailgate Width (in): - TBD -
• Cargo Volume (ft³): 58.6
• Interior Dimensions
• Passenger Capacity: 3
• Front Head Room (in): 40.8
• Front Leg Room (in): 40.9
• Front Shoulder Room (in): 63.8
• Front Hip Room (in): 61.0
• Summary
• Vehicle Name: Ford F-150 Heritage
• Body Style: Reg Cab 6.5' Styleside
• Body Code: 119.9" WB
